Detailed Description

A basic signal reader that simplifies reading the signals's samples.

Public Member Functions
virtual ErrCode INTERFACE_FUNC	getValueReadType (SampleType *sampleType)=0
	Gets the sample-type the signal value samples will be converted to when read or `SampleType::Invalid` if read-type has not been determined yet. More...

virtual ErrCode INTERFACE_FUNC	getDomainReadType (SampleType *sampleType)=0
	Gets the sample-type the signal domain samples will be converted to when read or `SampleType::Invalid` if read-type has not been determined yet. More...

virtual ErrCode INTERFACE_FUNC	setValueTransformFunction (IFunction *transform)=0
	Sets the transform function that will be called with the read value-data and currently valid Signal-Descriptor giving the user the chance add a custom post-processing step. The function should have a signature compatible with: More...

virtual ErrCode INTERFACE_FUNC	setDomainTransformFunction (IFunction *transform)=0
	Sets the transform function that will be called with the read domain-data and currently valid Signal-Descriptor giving the user the chance add a custom post-processing step. The function should have a signature compatible with: More...

virtual ErrCode INTERFACE_FUNC	getReadMode (ReadMode *mode)=0
	Gets the reader's read mode which determines if the reader will also scale the read data or not. More...

Public Member Functions inherited from IReader
virtual ErrCode INTERFACE_FUNC	getAvailableCount (SizeT *count)=0
	Gets the number of segments available to read. More...

virtual ErrCode INTERFACE_FUNC	setOnDataAvailable (IProcedure *callback)=0
	Sets the specified callback function to be called when there is available data in the reader. More...

virtual ErrCode INTERFACE_FUNC	setExternalListener (IInputPortNotifications *listener)=0
	Sets an external listener to the reader. More...

virtual ErrCode INTERFACE_FUNC	getEmpty (Bool *empty)=0
	Checks if there is data to read. More...

Public Member Functions inherited from IBaseObject
virtual ErrCode INTERFACE_FUNC	borrowInterface (const IntfID &intfID, void **obj) const =0
	Returns another interface which is supported by the object without incrementing the reference count. More...

virtual ErrCode INTERFACE_FUNC	dispose ()=0
	Disposes all references held by the object. More...

virtual ErrCode INTERFACE_FUNC	getHashCode (SizeT *hashCode)=0
	Returns hash code of the object. More...

virtual ErrCode INTERFACE_FUNC	equals (IBaseObject other, Bool equal) const =0
	Compares object to another object for equality. More...

virtual ErrCode INTERFACE_FUNC	toString (CharPtr *str)=0
	Returns a string representation of the object. More...

Public Member Functions inherited from IUnknown
virtual ErrCode INTERFACE_FUNC	queryInterface (const IntfID &intfID, void **obj)=0
	Returns another interface which is supported by the object and increments the reference count. More...

virtual int INTERFACE_FUNC	addRef ()=0
	Increments the reference count for an interface on an object. More...

virtual int INTERFACE_FUNC	releaseRef ()=0
	Decrements the reference count for an interface on an object. More...

Member Function Documentation

◆ getDomainReadType()

virtual ErrCode INTERFACE_FUNC getDomainReadType ( SampleType * sampleType )

pure virtual

Gets the sample-type the signal domain samples will be converted to when read or SampleType::Invalid if read-type has not been determined yet.

Parameters

[out] sampleType The sample-type type of the read samples otherwise SampleType::Invalid.

◆ getReadMode()

virtual ErrCode INTERFACE_FUNC getReadMode ( ReadMode * mode )

pure virtual

Gets the reader's read mode which determines if the reader will also scale the read data or not.

Parameters

[out] mode The mode the reader is in (either Raw or Scaled)

◆ getValueReadType()

virtual ErrCode INTERFACE_FUNC getValueReadType ( SampleType * sampleType )

pure virtual

Gets the sample-type the signal value samples will be converted to when read or SampleType::Invalid if read-type has not been determined yet.

Parameters

[out] sampleType The sample-type type of the read samples otherwise SampleType::Invalid.

◆ setDomainTransformFunction()

virtual ErrCode INTERFACE_FUNC setDomainTransformFunction ( IFunction * transform )

pure virtual

Sets the transform function that will be called with the read domain-data and currently valid Signal-Descriptor giving the user the chance add a custom post-processing step. The function should have a signature compatible with:

transform(Int inputBuffer, Int outputBuffer, SizeT toRead, IDataDescriptor* descriptor)

IDataDescriptor

Describes the data sent by a signal, defining how they are to be interpreted by anyone receiving the ...

Definition: data_descriptor.h:125

Parameters

transform The function performing the post-processing.

◆ setValueTransformFunction()

virtual ErrCode INTERFACE_FUNC setValueTransformFunction ( IFunction * transform )

pure virtual

Sets the transform function that will be called with the read value-data and currently valid Signal-Descriptor giving the user the chance add a custom post-processing step. The function should have a signature compatible with:

transform(Int inputBuffer, Int outputBuffer, SizeT toRead, IDataDescriptor* descriptor)

Parameters

transform The function performing the post-processing.
